ET-7051
16-channel Isolated Digital Input Data Acquisition Module with 32-bit Counters, communicable over Ethernet and Modbus TCP Protocol. Supports operating temperatures between -25°C to 75°C.
Features
The ET-7000/PET-7000 series, a web-based Ethernet I/O module, features a built-in web server which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. Remote control is as easy as surfing the Internet.
Besides, with the web HMI function, no more programming or HTML skills are required; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The ET-7000/PET-7000 series offers easy and safe access for users from anytime and anywhere! In addition, the ET-7000/PET-7000 series also supports Modbus/TCP protocol that makes perfect integration to SCADA software.
Furthermore, P/ET-7000 series features "PoE" that not only data but also power is carried through an Ethernet cable. This feature makes installation of PET-7000 series modules a piece of cake. Imagine that no more unnecessary wires, only an Ethernet cable takes care of everything in the field.
- PoE and Regular Ethernet Options
- Built-In Web Server
- Web HMI
- Modbus/TCP, Modbus/UDP Protocol
- Communication Security
- Dual Watchdog
- Operating Temperature: -25 ~ +75 °C
- I/O Pair Connection
- Built-In I/O
- DI/Counter: 16 Channels
Applications
Building Automation, Factory Automation, Machine Automation, Remote Maintenance, Remote diagnosis, Testing Equipment.
ET-7051 comes with FREE EZ Data Logger Software.
Specifications
| Software | |
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
| Communication | |
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 second), Communication (Programmable) |
| LED Indicators | |
| L1 (System Running) | Yes |
| L2 (Ethernet Link/Act) | Yes |
| L3 (Ethernet 10/100 M Speed) | Yes |
| PoE Power | - |
| 2 Way Isolaiton | |
| Ethernet | 1500 VDC |
| I/O | 3750 Vrms |
| EMS Protection | |
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal |
| EFT (IEC 61000-4-4) | +/-2 kV for Power |
| Power Requirements | |
| Reverse Polarity Protectionn | Yes |
| Powered from terminal block | Yes, 10 ~ 30 VDC |
| Powered from PoE | - |
| Consumption | 2.2 W |
| Mechanical | |
| Dimensions (W x L x D) | 72 mm x 123 mm x 35 mm |
| Installation | DIN-Rail or Wall mounting |
| Environment | |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
I/O Specifications
| Digital Input/Counter | |||
| Input Channels | 16 | ||
| Type | Wet Contact (Sink, Source) | ||
| On Voltage Level | +10 VDC ~ +50 VDC | ||
| Off Voltage Level | +4 VDC max. | ||
| Input Impedance | 10 kΩ | ||
| Counters | Max. Count | 4,294,967,285 (32 bits) | |
| Max. Input Frequency |
500 Hz | ||
| Min. Pulse Width | 1 ms | ||
| Overvoltage Protection | +70 VDC | ||
