WinGRAF

Win-GRAF is the most powerful SoftLogic IEC 61131-3 development environment packages in the world. Unlike ISaGRAF, WinGRAF is a PLC Like software that is supported on Windows7, 8, 10.

Using the Win-GRAF software with ICP DAS Win-GRAF PACs, the control/monitor systems can easily implement the industrial level of data acquisition and logic control in various industrial fields.

Applications

• Data Acquisition System
• Factory Automation
• Building Automation
• Remote I/O system
• Wireless Monitor/Control System
• Motion Control System and so on

• Support eLogger HMI

• Support Win-GRAF Redundant Solution
• Modbus Master Protocol
• Modbus Slave Protocol
  • Multi-port Modbus RTU Slave, RS-232/485/422.
  • Modbus TCP Slave (Multiple connections).
  • Connect PC/SCADA/HMI.
• Support DCON I/O
  • Support RS-485 Port to connect the ICP DAS I-7000 I/O modules, and I-87K4/5/8/9 Expansion Unit plus I-87K High Profile I/O modules, and RU-87P4/8 Expansion Unit plus I-87K High Profile I/O modules.
• Support Temperature/Humidity Modules
  • DL-100T485 and DL-100TM485.
• Support a Variety of I/O Modules
  • Support I-8K and I-87K High Profile I/O modules, such as DI, DO, AI, AO, Relay, AC-IN, Thermistor, Thermocouple, RTD, Strain Gauge, Encoder, PWM output, Counter, Frequency, etc.
• Support File Access & Data Log
• Schedule-Control
• Support Retain Variables
  • All Win-GRAF PACs support retain variables. Suitable to retain the data changed quickly and frequently.
• Protect Application by Own Algorithm
  • Win-GRAF PAC is equipped with a unique 64-bit hardware serial number. It can be used to generate a license key to protect the software against illegal copies. Protect the Win-GRAF application by the user-defined algorithm. Even others copy the application to the same model PAC, as long as he cannot get the source code, cannot run the application correctly.
• Support VS 2008 Development
  • The Win-GRAF PACs support to use VS 2008 (VB.net, C#) to develop user own HMI and data management programs, and can exchange variables with the Win-GRAF control programs.
