Touchpad 4.3'' Touch Screen PLC / Touch Screen Controller with Ethernet, RS-485 and USB ports, Real Time Clock and fits in regular electrical wall mount outlets. Supports Modbus RTU and Modbus TCP protocols. Comes with Free HMIWorks C Language and Ladder Logic Programming Development Environment. Supports operating temperatures between -20 ~ +50°C (-4F ~ 122F).  TPD-433F has a flange mount and TPD-433-EU is the European Version.

TPD-433-H

Touchpad 4.3" Touch Screen PLC / Touch Screen Controller with Ethernet, RS-485 and USB ports, Real Time Clock and fits in regular electrical wall mount outlets. Supports Modbus RTU and Modbus TCP protocols. Comes with Free HMIWorks C Language and Ladder Logic Programming Development Environment. Supports operating temperatures between -20 ~ +50°C (-4F ~ 122F). TPD-433F has a flange mount and TPD-433-EU is the European Version.

  Price:  $519.00

Fastest Delivery: (Details) X Delivery Details
We ship via UPS and fastest delivery is with Next Day Air. UPS Next Day Air Early typically gets their product to them as early as 8am, Next Day Air gets their product typically there by 10:30am and Next Day Air Saver typically by 3pm. We ship same day for in stock items and the lead time is up to one week for out of stock items. Delivery is dependent on UPS and your shipping method.
ADD TO CART
ADD TO CART
BUY BY 1-CLICK

Features

Applications

The TPD-433 TouchPAD is a tiny touch HMI PLC designed for building and home automation. The TPD-433 PLC is equipped with a high resolution TFT color touch screen and fits in with regular electrical wall-mount outlets. It seamlessly integrates with rich I/O modules and presents a beautiful, flexible and user-defined picture interface. In short, it is the best choice to upgrade mechanical switches to intelligent control pads.

For PLC users HMIWorks provides Ladder Designer, and for IT users, a C language environment is provided. It takes less than 30 minutes to learn how to create a GUI application program for the TPD-series devices when using Ladder Designer. With all the features provided, TPD-series touch HMI Devices must be the most cost effective HMI Device in the history of the market.

  • Excellent C/P ratio (cost/performance)
  • High-resolution color touch screen
  • Ethernet
  • RTC (Real Time Clock)
  • Speaker
  • WYSIWYG (What You See Is What You Get) GUI design
  • Free HMIWorks development tool
  • Supports the popular C programming language
  • Supports Ladder Designer
  • ESD Protection: 4 kV
  • Operating temperature: -20 ~ 70°C

TPD-433F
TPD-433F rear view

Specifications

CPU Module

CPU

32-bit RISC CPU

Memory

16 MB SDRAM / 8 MB Flash

Real Time Clock (RTC)

Yes

Rotary Switch (0~9)

Yes

Communication Interface

Serial Port

RS-485 (including Self-Tuner)

Ethernet

Yes (RJ-45 x 1, 10/100 Base-TX)

USB 1.1 Client

Firmware updates only

MMI (Main Machine Interface)

LCD

4.3” TFT(Resolution 480 X 272 X 16), Bright pixels <= 3

Backlight Life

20,000 hours

Brightness

400 cd/m2

Touch Panel

Yes

LED Indicator

Yes

Reset Button

Yes

Electrical

Power Input Range

+10 ~ 30 VDC

Powered from PoE

IEEE 802.3af, Class1 (48 V)

Power Consumption

2.5 W (104 mA @ 24 VDC)

Mechanical

Dimensions (W x L x H)

126 mm x 82 mm x 24 mm

Installation

Wall Mount (Suitable for the outlet box in United States)

Environmental

Operating Temperature

-20 ~ +50 °C

Storage Temperature

-30 ~ +80 °C

Ambient Relative Humidity

10 ~ 90% RH, non-condensing
