TPD-280
TPD-280 2.8" Compact Touchpad Touch Screen HMI Controller with high resolution 2.8 inch TFT color touch screen, USB port and Real Time Clock. Communicable over RS-485 and Modbus RTU. Includes free HMIWorks software for Ladder Logic and C language programming and GUI development environment. Can fit in electrical wall outlets. Supports operating temperatures between -20 ~ +70°C (-4F ~158F).
Features
***This Product is phased out and replaced by TPD-280-H ***
The ICP DAS Touchpad is a small touch screen controller HMI designed for building and home automation and supports Modbus protocols. TPD-280 and TPD-280U touch screen HMI's are equipped with a high resolution 2.8'' TFT color touch screen, 32-bit RISC CPU, and RS-485 serial port. TPD-280U also features a real time clock and a USB port for convenient interfacing with a PC. TPD-280/U touch screen controller supports Modbus RTU protocols.
|
|
![]() |
Fits in Regular Wall Outlets ![]() |
Specifications
Models | TPD-280 | |
CPU Module | ||
CPU | 32-bit RISC CPU | |
Memory Expansion | - | |
Real Time Clock (RTC) | - | |
Buzzer | Yes | |
Rotary Switch (0~9) | Yes | |
Communication Interface | ||
Ethernet | - | |
Serial Port | RS-485 (including Self-Tuner) | |
USB 1.1 Client | - | |
Main Machine Interface(MMI) | ||
LCD | 2.8 TFT (Resolution 240 x 320 x 16), defective pixels <= 3 | |
Backlight Life | 20,000 Hours | |
Backlight Life | 20,000 Hours | |
Brightness | 160 cd/m2 | |
Touch Panel | Yes | |
Reset Button | Yes | |
Electrical | ||
Powered from Terminal Block | +10 ~ 30 VDC | |
Power Consumption | 1.2 W | |
Mechanical | ||
Dimension (W x L x H) | 76 mm x 119 mm x 33 mm | |
Wall Mount | Yes | |
Ingress Protection | Front Panel: IP40 | |
Environmental | ||
Operating Temperature | -20 ~ +70 °C | |
Storage Temperature | -30 ~ +80 °C | |
Ambient Relative Humidity | 10 ~ 90% RH, non-condensing |
