4 Channel RTD Input Module. I-87013 is phased out and replaced by I-87013W.

I-87013

4 Channel RTD Input Module. I-87013 is phased out and replaced by I-87013W.

    Item Not Available


Features

The I-87013 has officially been phased out and will no longer be available. It has now been replaced by I-87013W.

I-87013 has a serial bus (RS-485) communication interface with DCON protocol. It can be plugged into our WinCon, LinCon, I-8000 controllers and I-87K, RF-87K I/O expansion units. I-87013 is a 4 Channel RTD Input Module with 8 channels. I-87013 is a serial cartridge based I/O module that offers the ultimate in cost effective flexibility.

Specifications

  • Serial I/O Module
  • Analog Input Channels: 4
  • Input Type: Pt, Ni
  • Resolution: 16-bit
  • Sampling rate: 10 samples/sec
  • Bandwidth: 15.7Hz
  • Wire connection: 2/3/4
  • Accuracy: ± 0.1% or better
  • Zero drift: ±0.5┬ÁV/ °C
  • Span drift: ±25 ppm/°C
  • CMR @ 50/60 Hz: 150dB min.
  • NMR @ 50/60 Hz: 100 dB
  • Over voltage protection: +/- 35 V
  • Power Consumption:0.8W
RTD temperature range
Pt100 -100°C

to

+100°C α=0.00385
Pt100 0°C to +100°C α=0.00385
Pt100 0°C to +200°C α=0.00385
Pt100 0°C to +600°C α=0.00385
Pt100 -100°C to +100°C α=0.003916
Pt100 0°C to +100°C α=0.003916
Pt100 0°C to +200°C α=0.003916
Pt100 0°C to +600°C α=0.003916
Ni120 -80°C to +100°C
Ni120 0°C to +100°C
