Ethernet I/O Module with 2-port Ethernet Switch, 8 AC/DC digital input channels. Each input channel can be used as a 32-bit counter. Support for both Modbus TCP and Modbus UDP Protocols. Built-in Web Server. Has operating temperatures of -25°C ~ +75°C (-13°F ~ +167°F).

ET-7259

Ethernet I/O Module with 2-port Ethernet Switch, 8 AC/DC digital input channels. Each input channel can be used as a 32-bit counter. Support for both Modbus TCP and Modbus UDP Protocols. Built-in Web Server. Has operating temperatures of -25°C ~ +75°C (-13°F ~ +167°F).

  Price:  $369.00

Fastest Delivery: (Details) X Delivery Details
We ship via UPS and fastest delivery is with Next Day Air. UPS Next Day Air Early typically gets their product to them as early as 8am, Next Day Air gets their product typically there by 10:30am and Next Day Air Saver typically by 3pm. We ship same day for in stock items and the lead time is up to one week for out of stock items. Delivery is dependent on UPS and your shipping method.
ADD TO CART
ADD TO CART
BUY BY 1-CLICK

References & Support


Features

Ethernet I/O Module with 2-port Ethernet Switch, 8 AC/DC digital input channels. Each input channel can be used as a 32-bit counter. Support for both Modbus TCP and Modbus UDP Protocols. Built-in Web Server. Has operating temperatures of -25°C ~ +75°C (-13°F ~ +167°F).

  • Built-in Web Server
  • Web HMI
  • Support for both Modbus TCP and Modbus UDP Protocols
  • Communication Security
  • 2-port Ethernet Switch for Daisy-Chain Topology
  • Dual Watchdog
  • Wide Operating Temperature Range: -25 to +75°C
  • Built-in I/O
    • AC/DC Digital Input: 8 Channels

Specifications

Software

Built-In Web Server

Yes

Web HMI

Yes

I/O Pair Connection

Yes

Communication

Ethernet Port

2 x RJ-45, 10/100 Base-TX, Swtich Ports

PoE

-

Protocol

Modbus TCP, Modbus UDP

Security

ID, Password and IP Filter

Dual Watchdog

Yes, Module (0.8 seconds), Communication (Programmable)

LED Indicators

for System Running

Yes

for Ethernet Link/Act

Yes

for DI/DO status

Yes

for PoE Power

-

2 Way Isolation

Ethernet

1500 VDC

I/O

2500 VDC

EMS Protection

ESD (IEC 61000-4-2)

+/-4 kV Contact for Each Terminal and +/-8 kV Air for Random Point

EFT (IEC 61000-4-4)

+/-4 kV for Power Line

Power

Reverse Polarity Protection

Yes

Powered from Terminal Block

12 ~ 48 VDC

Powered from PoE

-

Consumption

2.3 W (Max.)

Mechanical

Dimensions (L x W x H)

120 mm x 76 mm x 38 mm

Installation

DIN-Rail or Wall mounting

Environmental

Operating Temperature

-25 to +75°C

Storage Temperature

-30 to +80°C

Humidity

10 to 90% RH, Non-condensing
