12-channel Form A Relay Output Module with LED Display, communicable over Modbus RTU, supports operating temperatures from -25 °C ~ +75 °C

M-7061D

write a review write a review

12-channel Form A Relay Output Module with LED Display, communicable over Modbus RTU, supports operating temperatures from -25 °C ~ +75 °C

Price: $329.00

Fastest Delivery:

Qty:

Compare

Compare: 0

ADD TO CART

BUY BY 1-CLICK

Email Product Details Write a Review Write a Review Email Us

References and Support Add to Quote

References & Support

Features

M-7000 intro M-7061 offers 12 channels for relay output. All of its channels are Form A type relay. M-7061 has 12 LED indicators for channel status as well as qualification for 4 kV ESD protection and 3750 Vrms intra-module isolation.

Support Relay Outputs
4 kV ESD Protection
3750 Vrms Intra-Module Isolation
RoHS Compliance
A Wide Range of Operating Temperature: -25 °C ~ 75 °C

Applications

Industry automation
Industrial Machinery
Building Automation
Food & Beverage
Semiconductor Fabrication
Control system

Specifications

Relay Output
Output Channels		12
Output Type		Power Relay, Form A ( SPST N.O.)
Contact Rating		250 VAC@5A 30 VDC@5A
Operating Time		6 ms
Release Time		3 ms
Zero Drift		+/- 20 μV/°C
Span Drift		+/- 25 ppm/°C
Electrical Life (Resistive load)	VDE:	5 A@250 VAC 30,000 ops (10 ops/minute) at 75°C.
		5 A@30 VDC 70,000 ops (10 ops/minute) at 75°C.
	UL:	5 A@250 VAC/30 VDC 6,000 ops.
		3 A@250 VAC/30 VDC 100,000 ops.
Mechanical Life		20,000,000 ops. at no load (300 ops./minute).
Intra-module Isolation, Field to Logic		3750 Vrms
ESD Protection		±4KV Contact for each terminal, and ±8KV Air for random point
EFT Protection		±4KV to Power
Surge Protection		±3 kV for Power Input.

System Specifications

Interface
Interface	RS-485
Format	N, 8, 1
Baud Rate	1200 ~ 115200bps
LED Display
1 LED as Power/Communication indicator
12 LEDs as Relay Output indicators (for M-7061D)
Power
Input Voltage Range	10 ~ 30 VDC
Power Consumption	1.7 W (max.)(M-7061)/2.3 W (max.)(M-7061D)
Protocol
Support Modbus and DCON Protocol	Yes
Environment
Operating Temperature	-25 °C ~ +75 °C
Storage Temperature	-40 °C ~ +85 °C
Humidity	10 ~ 95% RH, Non-condensing
