3-Axis, 32 Bit Encoder Counter with Display communicable over RS-485. Supports operating temperatures between -25 to 75°C.

I-7083D (with display)

3-Axis, 32 Bit Encoder Counter with Display communicable over RS-485. Supports operating temperatures between -25 to 75°C.

  Price:  $439.00

Features

I-7080D is designed to provide signal conditioning system monitoring and safe value settings. I-7080 is a Counter/Frequency Input Module with a display. It is a cost-effective solution for a wide range of valuable industrial control signals and systems. The DCON utility can help users to configure and test I-7080 High Speed Counter / Frequency Input module. Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems. The communication interface is modbus protocol via RS-485. Users may mount the modules on a DIN rail, panel or wall. Modules have a screw-terminal block to connect to the signals.

Specifications

  • Counter Input
    • Channels: 3 Asix
    • Input Type: Isolated
    • Encode Mode:
      • Quadrant Counting Mode
      • CW/CCW Counting MOde
      • Pulse/Dir Counting MOd
    • Isolation Voltage:
      • Input Level: 5V
        • Logic High: 3.5V - 5V
        • Logic Low: 0V - 2V
      • Input 12V with External Resistor 1K Ohm
        • Logic High: 5V - 12V
      • Input 24V with External Resistor 2K Ohn
        • Logic High: 7V - 24V
        • Logic Low: 0V - 2V
      • Maximum Count: 32 bit
      • Maximum Counting Rate: 1 Mhz
  • Interface: RS-485
    • Format: N, 8, 1
    • Baud Rate: 1200 - 115200bps
  • LED Display:
    • 1 LED as Power / Communication Indicator
    • 5-digit readout (for I-7083D)
  • Power
    • Input Voltage Range: 10 - 30VDC
    • Power Consumption:
      • 1.5W max. for I-7083
      • 1.7W for max. I-7083D
  • Environment
    • Operating Temperature: -25°C to 75°C
    • Storage Temperature: -40°C to 85°C
    • Humidity: -5% to 95% (non-condensing)
