I-7059
8 Channel Isolated AC Voltage Digital Input (16-bit Counters) Data Acquisition Module communicable over RS-485. Supports operating temperatures between -25°C ~ +75°C (-13°F ~ +1677deg;F).
Features
8-channel Isolated AC Voltage Digital Input Module I-7059D : I-7059 with LED Display
Specifications
Digital Input | |
Channels | 8 |
Input Type | AC, Differential, isolated |
Off Voltage Level | 3 VAC max. |
On Voltage Level | 10~80 VAC |
AC Frequency | 47~400Hz (> 45Hz min) |
Input Impedance | 10K Ohm, 1W |
Counters | channels : 8 |
Max. Counts: 16-bit (65535) | |
Max. Input Frequency : 100Hz | |
Min. Pulse Width : 5ms | |
Photo-Isolation | 5000Vrms |
Interface | |
Interface | RS-485 |
Format | N, 8, 1 |
Baud Rate | 1200 ~ 115200bps |
LED Display | |
1 LED as Power/ Communication indicator | |
8 LEDs as Digital Input indicators (for I-7059D) | |
Power | |
Input Voltage Range | 10~30VDC |
Power Consumption | 0.3 W (max.)(I-7059) / 1.0W (max.)(I-7059D) |
Environment | |
Operating Temperature | -25 to 75°C |
Storage Temperature | -40 to 85°C |
Humidity | 5 to 95%, non-condensing |
